Scheda di sviluppo P32Board
La scheda di sviluppo P32Board è un sistema completo che permette di sviluppare molte applicazioni con la famiglia di microcontrollori PIC32MZ, senza richiedere l’aggiunta di hardware esterno. In particolare, possono essere sviluppate applicazioni con display LCD 16x2, applicazioni con protocollo SPI, I2C, UART e applicazioni con ingressi analogici o digitali. In aggiunta, è possibile connettere qualsiasi hardware esterno grazie ai connettori di espansione. La compatibilità della scheda con i programmatori e i debugger di casa Microchip la rendono inoltre integrabile nel sistema di sviluppo MPLAB X.
Autore: Ivo Colleoni
3D printed PCB assembly test fixture
The design phase is the most important part within a new product development cycle. Investing enough time on it, is fundamental for good quality products. Nevertheless spending enough time in testing a new system is also as much important as the design phase. Only by testing a real system is possible to properly validate how the integration of the sub-modules are affecting each other. Last but not least, during the test phase it is possible to check how the system usability is. In this article it will be presented a 3D printed fixture to test new assembled PCBs that come back on our desk. The fixture has been designed to be flexible enough and be used in various scenarios enabling a quick PCB Assembly (PCBA) test and replacement.
Dallo schema elettrico al PCB
Realizzare un sistema elettronico, necessita il passaggio per varie fasi e un certo numero di iterazioni al fine di rendere il progetto finale quanto più funzionale possibile. Le varie fasi possono variare a seconda dell’applicazione e soprattutto se il progetto debba essere catalogato come “Maker” o “professionale”. Frequentemente in sistemi Maker, non ci si preoccupa molto della fase progettuale e si pone ad essa poco tempo. La realizzazione è spesso anche fatta velocemente al fine di realizzare pezzi unici. Quando si voglia realizzare un sistema professionale le cose cambiano. La fase progettuale diventa una fase importante della progettazione come anche la fase di test del sistema, al fine di verificare che le specifiche di progetto siano rispettate.
PCB Layout - PCB ground layer considerations
Old system assemblies, based on vacuum tubes, were often made directly on the manufacturing floor without any PCB support. With the increased signal frequency and system integration, made possible by transistors and ICs, using a PCB was a must. Nevertheless, till the 80’, regulations were not covering commercial products as they do today. EMC (Electromagnetic Compatibility) and immunity tests are today part of the system requirements that may challenge the designer during the design phase. High-speed applications, precision analog, and the regulations that the system must fulfill, make the PCB a fundamental part of the design puzzle. In this article, we will take a closer look at the PCB ground layer. Using it is very important, but sometimes it could lead to more problems than benefits...
PCB Layout - understand stray capacitance and inductance
The PCB board layout is the last challenge after having designed the schematic. While things may work on sub-modules level, once all the system gets assembled on the PCB, additional problems may occur. Several “Tips and Tricks Cookbooks” are providing recommendations to the designer making the PCB layout the right way. Nevertheless properly understanding the limitation and boundary conditions at which a certain rule can be used, is fundamental. Thus, in this article, rather than talking about “Tips and Tricks” we will go down to the details of understanding from where the stray capacitance and inductance come from. Indeed, the two are responsible of the major problems a wrong layout may cause at system level.
